FsCDK Multi-Tier Application Example
This example demonstrates how to build a complete multi-tier web application using FsCDK with AWS best practices.
Architecture Overview
Architecture Details
This example demonstrates a production-ready multi-tier application with security best practices: - High Availability: Multi-AZ deployment across 2 availability zones - Security: VPC isolation, security groups, encryption at rest and in transit - Scalability: Auto-scaling Lambda, Multi-AZ RDS with read replicas - Performance: CloudFront CDN for global content delivery
Architecture Diagram
Production-ready multi-tier web application showing VPC network segmentation, security zones, and data flow. Components: CloudFront CDN → Application Load Balancer → Lambda Functions → RDS PostgreSQL, with S3 static assets and Cognito authentication.
Key Components: - CloudFront CDN: Global content delivery with HTTPS/TLS 1.2+ - Application Load Balancer: Multi-AZ load balancing in public subnets - Lambda Functions: Serverless compute in private subnets with auto-scaling - RDS PostgreSQL: Multi-AZ database with encryption and automated backups - S3: Static asset storage with versioning and encryption - Cognito: Managed authentication and user management
Security Layers: - Public subnets: ALB with internet-facing access - Private subnets: Lambda and RDS with no direct internet access - Security groups: Least-privilege network access control - NAT Gateway: Controlled outbound internet access for private resources
Network Flow: 1. User requests → CloudFront → Internet Gateway → ALB (public subnet) 2. ALB → Lambda functions (private subnet, security group SG-Lambda) 3. Lambda → RDS database (private subnet, security group SG-Database, inbound only from SG-Lambda) 4. Lambda outbound → NAT Gateway → Internet Gateway (for API calls) 5. Static content → S3 → CloudFront cache
Note: To generate this diagram, use the specifications in
docs/img/DIAGRAM_SPECIFICATIONS.mdwith tools like Cloudcraft, Draw.io, or Lucidchart.
Example Stack
#r "../src/bin/Release/net8.0/publish/Amazon.JSII.Runtime.dll"
#r "../src/bin/Release/net8.0/publish/Constructs.dll"
#r "../src/bin/Release/net8.0/publish/Amazon.CDK.Lib.dll"
#r "../src/bin/Release/net8.0/publish/System.Text.Json.dll"
#r "../src/bin/Release/net8.0/publish/FsCDK.dll"
open Amazon.CDK
open Amazon.CDK.AWS.S3
open Amazon.CDK.AWS.RDS
open Amazon.CDK.AWS.EC2
open Amazon.CDK.AWS.Lambda
open Amazon.CDK.AWS.Cognito
open Amazon.CDK.AWS.CloudFront
open FsCDK
Best Practices Demonstrated
Security
- Least Privilege: Security groups deny all by default
- Encryption: RDS and S3 use encryption at rest
- Strong Authentication: Cognito with MFA and strong password policy
- Private Subnets: Database and Lambda in private subnets
- No Public Access: Database not publicly accessible
High Availability
- Multi-AZ: VPC spans multiple availability zones
- Multi-AZ RDS: Database replicated across AZs
- Automated Backups: 7-day retention with preferred window
- CloudFront CDN: Global content delivery
Cost Optimization
- Right-sized Instances: t3.small for RDS, appropriate memory for Lambda
- Single NAT Gateway: Development/staging configuration
- S3 Lifecycle Rules: Automatic transition to cheaper storage
- Regional CDN: PriceClass100 for US/Canada/Europe
Performance
- HTTP/2: CloudFront uses HTTP/2
- IPv6: Enabled for better connectivity
- Lambda Insights: Performance monitoring
- X-Ray Tracing: Distributed tracing enabled
Operational Excellence
- Automated Backups: RDS backup retention
- Auto Minor Upgrades: RDS automatically updates
- Monitoring: Lambda Insights and X-Ray
- Tagging: All resources properly tagged
Deployment
|
Environment Variables
Create a .env file:
AWS_ACCOUNT=123456789012
AWS_REGION=us-east-1
Monitoring
After deployment, monitor your application:
- CloudWatch Logs: Lambda function logs
- RDS Performance Insights: Database performance
- CloudFront Metrics: CDN performance and cache hit rate
- X-Ray Service Map: Distributed tracing visualization
Scaling
To scale for production:
- Increase NAT gateways to 2+ for HA:
natGateways 2 - Upgrade RDS instance:
instanceType (InstanceType.Of(InstanceClass.MEMORY5, InstanceSize.LARGE)) - Add more Lambda functions with ALB
- Expand CloudFront price class:
priceClass PriceClass.PRICE_CLASS_ALL
Cost Estimation
Approximate monthly costs (us-east-1) (at of Oct25):
- VPC + NAT Gateway: ~$32
- RDS t3.small (Multi-AZ): ~$50
- Lambda (1M requests, 512MB): ~$10
- S3 (100GB, with lifecycle): ~$2
- CloudFront (PriceClass100, 100GB transfer): ~$8.50
- Cognito (10k MAU): Free
Total: ~$102/month (excluding data transfer)
Security Checklist
- [x] All data encrypted at rest
- [x] All data encrypted in transit (TLS 1.2+)
- [x] Security groups follow least privilege
- [x] Database in private subnet
- [x] No hardcoded credentials
- [x] MFA available for users
- [x] Strong password policy enforced
- [x] Automated backups enabled
- [x] Deletion protection enabled
Next Steps
- Add Application Load Balancer for Lambda
- Implement API Gateway for REST API
- Add Route53 for custom domain
- Configure WAF for CloudFront
- Set up CloudWatch alarms
- Implement CI/CD pipeline
